CYG all in one battery with inverter 48V 51.2v LiFePO4 battery 10kw 15kw 20kw 30kw 40kw ESS Home Energy Storage Systems
SKU
Save 10%
Original price
$4,200.00
Original price
$4,200.00
-
Original price
$4,200.00
Original price
$4,200.00
Current price
$3,800.00
$3,800.00
-
$3,800.00
Current price
$3,800.00
In Stock & Ready to Ship
All orders are shipped within 1-2 business days. Product ETA 5-7 business days
Key attributes
Other attributes
Battery Type
Lithium Ion
Output Power Range
20-50 kWh
System Type
Wall-mounted, Stackable
Model Number
48V 51.2V Home energy storage system
Brand Name
CYG Powermate T5/T6/T8/T10
Place of Origin
Guangdong, China
Dimension (L*W*H)
depends energy
Weight
depends energy
Type
All-in-one
Communication Port
CAN, RS485, DRM/RCR, USB
Protection Class
IP65
Grid connection
Hybrid grid
Product name
ESS Lithium ion battery
Inverter optional
5kw/6kw/8kw/10kw
Operation Temperature
-20 ~ 45℃
Grid Connection
Three-phase
Battery
Lithium Iron
System Capacity
20kwh-40kwh
Pack Capacity
5.12kWh
System Voltage
204.8V~409.6V
Pack Operating Voltage Range
43.2-57.6V
Protection
IP65
Packaging and delivery
Selling Units:
Single item
Single package size:
20X40X1.5 cm
Single gross weight:
85.000 kg
Product Overview
Frequently bought together
PRODUCT SPECIFICATIONS
|
Model
|
PowermateT5
|
PowermateT6
|
PowermateT8
|
PowermateT10
|
|
Input (PV)
|
||||
|
Max PV Power
|
9000W
|
9000W
|
15000W
|
15000W
|
|
Max PV Voltage
|
1000V
|
|||
|
Max Input Current (PerMPPT)
|
15A/15A
|
15A/15A
|
20A/30A
|
20A/30A
|
|
MPPT Voltage Range
|
160V-950V
|
|||
|
Input (BAT)
|
||||
|
Compatible Batterytype
|
Lithium-ion/Lead-acid
|
|||
|
Nominal Battery Voltage
|
200V-600V
|
|||
|
Max.Charge/Discharge Current
|
25A/25A
|
25A/25A
|
50A/50A
|
50A/50A
|
|
Max.Charge/Discharge Power
|
9000W/5800W
|
9000W/7000W
|
15000W/9300W
|
15000W/10500W
|
|
Output (Grid)
|
||||
|
Nominal AC Output Power
|
5000W
|
6000W
|
8000W
|
10000W
|
|
Max.AC Output Current
|
3*8.3A
|
3*10A
|
3*13.3A
|
3* 16.7A
|
|
Rated AC Voltage
|
380V/400V/415V,3W+N+PE
|
|||
|
Grid Connection
|
Three-Phase
|
|||
|
Output (Backup)
|
||||
|
Nominal Output Voltage
|
230V
|
|||
|
Nominal Output Power
|
5000W
|
6000W
|
8000W
|
10000W
|
|
Nominal Output Current
|
3*7.6A
|
3*9.1A
|
3*12.2A
|
3* 15.2A
|
|
General
|
||||
|
Protection Grade
|
IP65
|
|||
|
Operating Temperature Range[℃]
|
-25℃~45℃
|
|||
|
Cooling Method
|
Natural Cooling
|
|||
|
Mounting
|
Wall Bracket
|
|||
|
Dimensions (W*H*D)
|
530mm*550mm*212mm
|
|||
|
Weight
|
30Kg
|
32Kg
|
||
|
HMI&COM
|
||||
|
Communication Interface
|
CAN/RS485(forBMS),DRM/RCR(forDI)/RS485(forMeter)1*DO, USB(Firmwareupgrade),Optional:WiFi/GPRS/4G/Ethernet
|
|||
|
Certification
|
||||
|
Safety
|
EN50549-1,IEC62109-1&2
|
|||
|
Grid
|
VDE-AR-N4105
|
|||
|
Model
|
PowermatePackT5.1
|
|||
|
Cell Technology
|
Lithium-ion(LFP)
|
|||
|
System Capacity
|
20kWh~40kWh
|
|||
|
Pack Capacity
|
5.12kWh
|
|||
|
System Voltage
|
204.8V~409.6V
|
|||
|
Pack Operating Voltage Range
|
43.2-57.6v
|
|||
|
Cycle Life
|
6,000cycles[90%DOD25℃]
|
|||
|
Max.Charge/Discharge Power
|
5.12kW
|
|||
|
Max.Charge/Discharge Current
|
50A/50A，0.5C/0.5C
|
|||
|
Available Charge/ Discharge Temperature Range
|
-20~+55°C
|
|||
|
Protection Grade
|
IP65
|
|||
|
Dimensions(W*H*D)
|
660*160*400mm
|
|||
|
Weight
|
53kg
|
|||
|
Certification
|
UN38.3.MSDS.IEC62619
|
|||
Products Description
Successful Project
Our Advantages
FAQ
Q1：Do you accept ODM/OEM orders?
A1：Yes, we can accept OEM/ODM, you can customize the logo and function，package as you want.
Q2： Which inverters can they be compatible with?
A2： Our lithium battery can interact with different inverters, such as Victron, DEYE,
Megarevo, GOODWE, VOLTRONICS, GROWATT, K-STAR, SOLIS, STUDER, SMA.
A2： Our lithium battery can interact with different inverters, such as Victron, DEYE,
Megarevo, GOODWE, VOLTRONICS, GROWATT, K-STAR, SOLIS, STUDER, SMA.
Q3：Can I visit your factory？
A3： Yes,you are welcomed to visited our factory any time
A3： Yes,you are welcomed to visited our factory any time
Q4:Are your lithium batteries safe?
A4：CYG storage batteries have multiple layers of safety protection and can also extinguish open flames in extreme cases with built-in aerosol.
